Vertical turn-milling CNC machine

Product Features

• The machine bed is made of integral casting and features a large contact area with the installation ground, ensuring greater stability. The Z-axis is designed with turning and machining center functions operating independently without interference. The fo
• All axes are driven by 40 mm ball screws with a 10 mm lead, ensuring high speed while keeping the drive motors operating within an optimal range. Each motion axis is supported by 45 mm linear roller guideways, which reduce motion resistance.
• This machine is a vertical turning-milling compound machine tool with independent Z-axis movements. The left and right sides operate separately for vertical motion. The Z-axis motion on the left side is used for turning tool cutting, with automatic tool c
• The machine features a fully enclosed integral guard with double doors, allowing convenient workpiece loading and unloading. The stainless steel telescopic covers offer enhanced durability, and the leak-proof structural design keeps the machine cleaner.
• Based on customer requirements, the spindle power, chuck size, and tooling functions can be modified accordingly to meet specific needs. A B-axis can also be added to enable multi-angle milling and drilling functions.
